Jackery SolarSaga 200W Solar Panel
| Wattage | Efficiency | IP Rating | Weight |
|---|---|---|---|
| 200W ±5% | ~25% (TOPCon Mono, Bifacial) | IP68 | 14.33 lbs (6.5 kg) |
Full 200W Solar Power
Rapid Recharge, Off-Grid Ready
Harness the sun with 200W of solar capture — enough to recharge compatible Jackery power stations significantly faster than a standard panel. Ideal for basecamp setups, overlanding rigs, and home backup systems that demand serious daily output.
High Efficiency — 25% Conversion Rate
TOPCon Monocrystalline Bifacial Cells
TOPCon monocrystalline cells capture up to 25% of available sunlight, and the bifacial design pulls in reflected light on the reverse side for extra yield — even on hazy days.
All-Weather Ready (IP68)
Dustproof & Waterproof
Built to IP68 standards, the SolarSaga 200W shrugs off rain, snow, dust, sand, and dirt for dependable performance in the field.
Simple & Speedy Setup
Fold-and-Go with Adjustable Stands
Lightweight, fold-flat construction with adjustable rear stands means the panel deploys in seconds and packs down just as fast.
Year-Round Reliability
Wide Operating Range
Rated from -4°F to 149°F (-20°C to 65°C), the panel performs consistently across seasons and climates.
Charge Multiple Devices
Built-In USB-A & USB-C Ports
Direct-charge phones, headlamps, and small electronics on the go via the integrated USB-A (5V/2.4A) and USB-C (5V/3A) ports — no power station required.
Sunlight Simplified
SolarTarget Angling Guide
The built-in SolarTarget tool helps you manually angle the panel for maximum sun exposure at any time of day.
| Electrical (STC) | |
| Peak Power (Pmax) | 200W ±5% |
| Open-Circuit Voltage (Voc) | 22V ±5% |
| Short-Circuit Current (Isc) | 12.5A ±5% |
| Power Voltage (Vmp) | 18V ±5% |
| Power Current (Imp) | 11.5A ±5% |
| Max System Voltage | 60V |
| Max Reverse Current | 15A |
| Physical | |
| Folded Dimensions | 23.62 x 23.50 x 1.57 in (600 x 597 x 40 mm) |
| Unfolded Dimensions | 89.76 x 23.50 x 0.98 in (2279 x 597 x 25 mm) |
| Weight | 14.33 lbs ±0.66 lbs (6.5 kg ±0.3 kg) |
| Environmental & Connectivity | |
| IP Rating | IP68 (dustproof & waterproof) |
| Operating Temperature | -4°F to 149°F (-20°C to 65°C) |
| Connector / Output Ports | DC8020 (adapter to DC7909 included), USB-A 5V/2.4A, USB-C 5V/3A |
| Warranty | 3-Year Standard + 2-Year Extended (5 Years Total) |
- SolarSaga 200W Solar Panel x1
- 3m Multi-Functional Cable with USB Ports x1
- DC8020 to DC7909 Adapter x1
- User Manual x1
Need a compatible connector for your specific Jackery power station? See our cable & adapter guide.
